MSI PRO Z890-S WIFI DDR5 ATX Motherboard - Black

The MSI PRO Z890-S WIFI DDR5 motherboard is built for Intel Core Ultra processors using the LGA1851 socket and delivers stable performance for gaming, professional workloads, and advanced computing tasks.
It combines PCIe 5.0 storage support, Thunderbolt 4 connectivity, WiFi 7 networking, and optimized power delivery to ensure fast data transfer, efficient thermal performance, and consistent system stability during intensive use.

Key Features

• Intel Z890 chipset
• LGA1851 socket for Intel Core Ultra processors
• DDR5 memory support up to 256GB
• PCIe 5.0 M.2 storage interface
• Thunderbolt 4 connectivity
• WiFi 7 wireless networking
• 2.5Gb Ethernet LAN
• EZ PCIe Clip II for easy GPU installation
• 12+1+1+1 digital power phase design
• Optimized PCB for higher bandwidth

Detailed Technical Specifications

• Model
  MSI PRO Z890-S WIFI DDR5

• Chipset
  Intel Z890

• CPU Support
  LGA1851 socket
  Supports Intel Core Ultra processors Series 2

• Memory
  4 DDR5 UDIMM slots
  Maximum capacity 256GB
  Memory speeds 8800 to 4800 MT/s depending on configuration
  Overclocking supported

• Expansion Slots
  1 PCIe 5.0 x16 slot from CPU
  1 PCIe 3.0 x1 slot
  2 PCIe 4.0 x4 slots

• Storage Support
  PCIe 5.0 M.2 storage support
  RAID support for SATA and NVMe devices

• Networking
  Realtek 2.5Gb LAN
  WiFi 7 wireless connectivity

• Thunderbolt
  1 Thunderbolt 4 rear port
  Up to 40Gbps data transfer
  Supports 8K display output

• USB Ports
  Rear USB Type-C 20Gbps
  Front USB Type-C 20Gbps
  Multiple USB Type-A 5Gbps ports
  Additional USB 2.0 ports

• Audio
  Realtek ALC897 codec
  7.1-channel high definition audio

• Cooling and Power
  12+1+1+1 digital VRM phases
  Dual CPU power connectors
  Additional PCIe power connector

• Internal Connectivity
  Multiple fan headers including pump support
  RGB and ARGB headers
  Thunderbolt expansion connector
  TPM 2.0 header

• BIOS and Software
  MSI Center support
  EZ Debug LED indicators

• Operating System Support
  Windows 11 64-bit

• Form Factor
  ATX
  Dimensions 243.84 × 304.8 mm

• Color
  Black with silver design theme
