Silverstone Triton 850RX 850W Gold PCle 5 ATX Power Supply - Black
The Triton 850Rx delivers reliable and efficient power for high-performance gaming and workstation PCs. Featuring ATX 3.1 and PCIe Gen 5 support with a 12V-2x6 connector, it’s built to handle the latest GPUs and components. With a Cybenetics Gold efficiency certification, Japanese electrolytic capacitors, and a compact 140mm depth design, it ensures stable performance, quiet cooling, and long-term durability.
Key Features
- 850W continuous DC output with 470.7 W/L power density.
- Supports PCIe Gen 5 with 12V-2x6 connector for next-gen GPUs.
- Cybenetics Gold efficiency (87%–89%) for reduced power loss and heat.
- Compact 140mm depth for easy installation in most ATX cases.
- 120mm ICB bearing fan with low noise level (18 dBA min.).
- Premium Japanese electrolytic capacitors for stability and reliability.
- Multiple protection systems: OPP, OCP, OVP, SCP, UVP, OTP.
- Fixed embossed black cables for neat and durable cable management.
Specifications
| Specification | Details |
|---|---|
| Product No. | SST-TR850R-GF |
| Model (Safety Certification) | SST-AX0850FCGD-A |
| Color | Black (lead-free paint) |
| Max. DC Output | 850W |
| Power Density | 470.7 W/L |
| +3.3V / +5V Max Load | 18A each (Combined 100W) |
| +12V Max Load | 70.8A (Combined 850W) |
| +5VSB / -12V Max Load | 3.0A / 0.3A |
| Input Voltage | 90 ~ 264 Vrms |
| Input Frequency | 47Hz ~ 63Hz |
| PFC | Active PFC (PF > 0.9 at full load) |
| Efficiency | 87% ~ 89% |
| MTBF | 100,000 hours |
| Operating Temperature | 0°C ~ 40°C |
| Protections | OPP, OCP, OVP, SCP, UVP, OTP |
| Connectors | 1x 24/20-pin MB, 2x 8/4-pin EPS, 1x 12+4-pin 12V-2x6, 5x 8/6-pin PCIe, 6x SATA, 2x 4-pin Peripheral |
| Cooling | Single 120mm ICB bearing fan |
| Noise Level | 18 dBA min. |
| Certification | Cybenetics Gold |
| Form Factor | ATX (PS2) |
| Dimensions (W x H x D) | 150 x 86 x 140 mm |
| Weight | 1.56 kg |
Package Contents
- Triton 850Rx Power Supply Unit
- Fixed black embossed cables (pre-attached)
- Power cord
- Mounting screws
-
User manual
